MUC.C.al SUV – this is how we imagine a real SUV

City e-bikes have many advantages, but are in terms of off-road suitability inferior to the normal eMTB. Messingschlager has taken on this subject and presents an interpretation of an all-road e-bike, ideal for on- and off-road use. It unites the advantages of a low-entry bike with more off-road mobility. The geometry and seating position promises in urban areas, as well as on gravel or forest paths a high degree of comfort and suitability for touring. Our SUV is equipped and well prepared for all eventualities that may come up on an e-bike on a weekend tour or a shopping trip to the weekly market. This is thanks to a powerful lighting system, elegant integration of ­mudguards and luggage racks as well as thick knobby tires.

The aluminum frame with comfortable geometry and low step trough entry is compatible with all Brose motors - Drive C, T or S - compatible. To increase flexibility to a maximum, we also offer here the option of a 522 Wh battery - for implementation of particularly cheaper price points - or a range extending 630 Wh battery. Open frame triangle for maximum flexibility (chain drive as well as belt drives possible without any problems).

Categorization:

Bike-Kategorie 2 Icon
Bike Detail 1

Our variable city platform makes a wide range of applications possible. With a bright lighting system and chunky, bulky tires this e-bike turns into a real SUV.

Bike Detail 2

Always everything in view! The Brose display central sits in the middle above the handlebars, impresses with its functionality and good readability, whether on- or offroad.

Bike Detail 3

Flexibility with the engine: this model can optionally be equipped with a Brose Drive C, Drive T or Drive S.


Key Facts

Key Features 1 Key Features 1

Driven by Brose Drive C, T or S motors, the customer has the option of 50, 70 or 90 Nm max. torque.

Key Features 2 Key Features 2

Maximum variability: thanks to the frame lock and construction, chain, hub and belt drives can be installed.

Key Features 3 Key Features 3

The battery, optionally in 522 or 630 Wh, is fully integrated in the frame and enables large ranges in an urban environment.

Key Features 4 Key Features 4

Coarse, voluminous tires up to 2.35“, elegantly integrated mudguard/­luggage rack unit, 80-100 mm suspension travel, high-quality lighting system – our interpretation of an SUV!


System

Systemkomponenten

Brose Display Central | Brose Drive C/T or S | battery with 522 or 630 Wh

With this frame platform, we offer the greatest possible variability and flexibility. Equipped with either Brose Drive C, T or S, the driving dynamics can be adapted to different purposes. With a maximum torque of 90 Nm, this e-bike feels at home in any area.

As an information center, we decided on the Brose Central Display, which thanks to its 3.5-inch color display offers a great overview and is linked to the Brose Display Remote and functions as a practical control unit.

For good ranges in urban areas, we offer two different batteries with 522 or 630 Wh for this platform. This means that nothing stands in the way of a long tour at the weekend or the daily commute to the office.


Geometry

Geometry Wave

Wave

WAVE S M L
Seat tube length 440 mm 490 mm 540 mm
Top tube length horizontal 612 mm 629 mm 645 mm
Steerer tube 170 mm 185 mm 200 mm
Chain stay 475 mm 475 mm 475 mm
Steerer tube angle 67° 67° 67°
Seat tube angle 70° 70° 70°
Seat tube angle 1124 mm 1141 mm 1159 mm
Reach 390 mm 402 mm 414 mm
Stack 644 mm 658 mm 671 mm
