Driven by Brose Drive C, T or S motors, the customer has the option of 50, 70 or 90 Nm max. torque.
Maximum variability: thanks to the frame lock and construction, chain, hub and belt drives can be installed.
The battery, optionally in 522 or 630 Wh, is fully integrated in the frame and enables large ranges in an urban environment.
Coarse, voluminous tires up to 2.35“, elegantly integrated mudguard/luggage rack unit, 80-100 mm suspension travel, high-quality lighting system – our interpretation of an SUV!
Brose Allround Display | Brose Drive S Mag | Akku with 522 or 630 Wh
With this frame platform, we offer the greatest possible variability and flexibility. Equipped with either Brose Drive C, T or S, the driving dynamics can be adapted to different purposes. With a maximum torque of 90 Nm, this e-bike feels at home in any area.
We opted for the Brose Allround Display as the information center. It keeps the rider up to date on all important tour dates at all times and still takes up little space on the handlebar.
For good ranges in urban areas, we offer two different batteries with 522 or 630 Wh for this platform. This means that nothing stands in the way of a long tour at the weekend or the daily commute to the office.
|Seat tube length||440 mm||490 mm||540 mm|
|Top tube length horizontal||612 mm||629 mm||645 mm|
|Steerer tube||170 mm||185 mm||200 mm|
|Chain stay||475 mm||475 mm||475 mm|
|Steerer tube angle||67°||67°||67°|
|Seat tube angle||70°||70°||70°|
|Seat tube angle||1124 mm||1141 mm||1159 mm|
|Reach||390 mm||402 mm||414 mm|
|Stack||644 mm||658 mm||671 mm|
