MMC.HT.al – Powerful e-hardtail with a wide range of uses

An E-MTB for all situations - our MMC.HT.al comes pretty close to this ideal. Whether on the narrow single trails of German low mountain ranges or on alpine gravel roads, the MTB hardtail meets all requirements perfectly.
Driven by proven Brose Mag generation 2 drives, the MMC.HT.al is designed for a wide range of uses in the touring sector and is recommended for suspension forks with 100–120 mm travel on 29" wheels or 120–140 mm travel on 27, 5" wheels.

The advantage of the concept lies in its great variability with useful details: Boost thru-axle standard, the option of mounting a dropper post with internal cable routing, flexible battery capacity from 522 Wh to 630 Wh for maximum range. The lightweight battery is elegantly integrated into the frame and ensures a clean, harmonious look. For the display, we recommend the universal and informative all-round display from Brose for all relevant information during an E-MTB tour.

Categorization:

Bike-Categorization 3 Icon
Bike Detail 1

Optimal full integration into the frame: lightweight batteries with 522 Wh for attractive price points or 630 Wh for maximum range.

Bike Detail 2

Elegantly integrated and still informative with all important tour data: the Brose LCD color display "Allround”.

Bike Detail 3

High flexibility: rear end with 12x148 mm Boost thru axles and for tire widths up to 29" x 2.4" or 27.5" x 2.8".

Key Facts

Key Features 1

In order to guarantee the greatest possible variability, our E-MTB hardtail was designed in such a way that both 27.5" and 29" wheels can be mounted.

Key Features 2 Key Features 2

Powerful Brose Drive S Mag drive with a maximum torque of 90 Nm and a weight of only 2.9 kg.

Key Features 3 Key Features 3

Flexible suitability for suspension forks up to 120 mm (29 ") or 140 mm (27.5") for a wide range of applications.

Key Features 4 Key Features 4

Optionally with 522 Wh or 630 Wh for maximum range or attractive price points.

System

System

Brose Allround Display | Brose Drive S Mag | Akku with 522 or 630 Wh

Our MTB hardtail frame is designed for the best possible all-round properties. It can optionally be equipped with Brose Drive C, S or T drives, depending on the desired driving dynamics and also with the Mag version.

The Brose Allround Display keeps the driver up to date with all important tour data at all times. Depending on the desired range and pricing, the hardtail platform can be specified with a 522 or 630 Wh battery.

Both the drive and the batteries are always optimally integrated into the frame. Perfect for a quick evening round or a long weekend tour.

Geometry

Geometry

Hardtail

HARDTAIL S/M M/L L/XL
Seat tube length 420 mm 460 mm 500 mm
Top tube length horizontal 606 mm 637 mm 659 mm
Steerer tube 160 mm 160 mm 170 mm
Chain stay 480 mm 480 mm 480 mm
Steerer tube angle 68° 68° 68°
Seat tube angle 73° 73° 73°
Wheelbase 1178 mm 1198 mm 1218 mm
Reach 405 mm 435 mm 455 mm
Stack 658 mm 663 mm 668 mm
Head set (S.H.I.S.) ZS44/28.6
ZS56/40		 ZS44/28.6
ZS56/40		 ZS44/28.6
ZS56/40
Fork installation height 503 mm 503 mm 503 mm
Seat post Ø 31.6 mm 31.6 mm 31.6 mm
